產品詳細說明
濾材為粗效過濾棉,容塵量大，阻力低
外框為鍍鋅框或鋁合金框
耐濕度可達100%
耐溫80℃
用于空調過濾 空壓機過濾 潔凈室過濾等
With synthetic fiber, big dust-holding capacity, low resistance
Frame :galvanized sheet or aluminum alloy
Humidity:100%
Temp.resistance:80℃
Air-condition, air compressor and clean room,etc
性能參數 specification
|
尺寸size W*H*D(mm) |
額定風量（m3/s）rated air flow |
初阻力(pa)initial resistance |
終阻力(pa)final resistance |
級別clss |
|
595*595*20mm |
1900 |
35 |
180 |
G3 |
|
290*595*20mm |
1000 |
35 |
180 |
G3 |
|
595*595*46mm |
3400 |
35 |
180 |
G3 |
|
290*595*46mm |
1700 |
35 |
180 |
G3 |
|
595*595*25mm |
1900 |
45 |
220 |
G4 |
|
290*595*25mm |
1000 |
45 |
220 |
G4 |
|
595*595*46mm |
3400 |
45 |
220 |
G4 |
|
290*595*46mm |
1700 |
45 |
220 |
G4 |
