通過認證
過濾性能好 容塵量大
濾袋邊緣采用超音波方式熔合 具有良好的氣密性及結合強度 不產生漏氣或破裂
耐濕度強 可達100%耐濕度
耐溫達80℃
空調過濾系統，無塵室，商場，醫院，電子廠，噴漆房等
Non-silicone synthetic fiber by hot melting way
High efficiency，large dust-holding capacity
Ultrasonic sealing make the edge of pocket with good strength, not easy to be broken
Humidity:100%
Temp.resistance:80℃
Application：air-condition system，clean room, shopping mall, hospital, electronics factory
and painting room, etc
性能參數specification
|
尺寸(mm)size W*H*D |
級別class |
袋數bags |
過濾面積(㎡)filtration area |
額定風量(m3/s) rated air flow |
初阻力(pa)initial resistance |
終阻力(pa)final resistance |
|
287*592*550 |
G3 |
3 |
1.86 |
1700 |
15 |
200 |
|
490*592*550 |
G3 |
5 |
3.12 |
2600 |
15 |
200 |
|
592*592*550 |
G3 |
6 |
3.78 |
3400 |
15 |
200 |
|
287*592*600 |
G4 |
3 |
2.12 |
2250 |
45 |
250 |
|
490*592*600 |
G4 |
5 |
3.66 |
3650 |
45 |
250 |
|
592*592*600 |
G4 |
6 |
4.40 |
4250 |
45 |
250 |
|
287*592*600 |
F5 |
3 |
2.12 |
1700 |
60 |
300 |
|
490*592*600 |
F5 |
5 |
3.66 |
2800 |
60 |
300 |
|
592*592*600 |
F5 |
6 |
4.40 |
3400 |
60 |
300 |
