產品詳細說明
玻璃纖維或聚丙烯濾紙
處理風量大 阻力小 使用壽命長
耐溫80℃
耐濕度
用于空調機組的終端過濾以及各種大風量空氣凈化
Glass fiber or polypropylene paper
Large air Volume, low resistance and long service time
Temp.resistance:80℃
Humidity:80%
Application:Air conditioning unit and various large volume air-cleaning system
性能參數specification
|
尺寸(mm)size H*W*D |
額定風量（CFM）rated air flow |
初阻力(pa)initial resistance |
終阻力(pa)final resistance |
型態form |
|
305*610*292 |
286 |
249PA |
500PA |
箱式型closed type |
|
610*610*292 |
2000 |
249PA |
500PA |
|
|
289*593*292 |
1000 |
270PA |
500PA |
單凸型opened type |
|
593*593*292 |
2000 |
270PA |
500PA |
